Indoor area controller
Product profile
The indoor area controller is used to cycle detect the status of the connected detector and upload the relevant information to the indoor node controller. The indoor area controller is used to connect the indoor node controller, parking space detector, LED display, etc., using RS485 and CAN bus hybrid communication mechanism to solve the problems of unreliable long-distance communication, network node expansion, packet management, etc.
Product advantages
1) Using the international advanced 32-bit ARM processor, full industrial grade design, to ensure the stability and reliability of products;
2) The whole system controller can be upgraded remotely, convenient for system maintenance and upgrade, always to meet the needs of users;
3) Using CAN and RS485 hybrid networking, strong networking ability, stable and reliable data communication, long transmission distance;
4) Independent dual RS485 interface design, single circuit can be up to 25 equipment, detector can be large capacity, high efficiency;
5) The equipment has the functions of short circuit, overvoltage and overload protection to prevent the electrical damage to the relevant equipment caused by wiring errors during construction;
6) The overall use of industrial design, after strict electrostatic, lightning and surge, group pulse and other testing, effectively ensure the reliable use of equipment;
7) It can quickly and effectively detect various states of the equipment, detect the communication situation of RS485 device with one key after installation, and quickly diagnose the bus connection situation.
8) Support for remote upgrade.
Technical Parameters
| product model | WBP-K02Z | working voltage | AC 110～240V |
| specification and dimension | 320×2 60× 90 mm | working temperature | - 3 0~ + 75℃ |
| net weight | 3. 5 Kg | communication mode | 1 CAN 2 RS485 |
| sheathing material | galvanized sheet | communication distance | CAN：≤1000m
RS485：≤ 300 m |
| Node capacity | 50 (including detector and guide split screen) | power dissipation | 2 W (self-power consumption, without detector) |
Product installation
ndoor area controller is generally installed on the column or wall, it is recommended to install the height of 2 meters and above. The installation diagram is shown in Figure
Use and maintenance
1) Non-system maintenance personnel shall not operate the system equipment at will to prevent misoperation and cause system failure.
2) After the system configuration file is completed, please make a backup to prevent it cannot be restored after damage.
3) When replacing the faulty equipment, please disconnect the power of the equipment and operate to prevent the equipment from burning during the operation.
4) When the system cannot work normally, please check the power supply of each equipment first and whether it is turned off by mistake.
Example diagram of the site installation
-
